Stasis Drilling Solutions is a privately held oilfield service company incorporated in Bossier City, LA with our corporate office being based in Houston, TX U.S.A. At Stasis we strive to advance the way wells are drilled by utilizing MPD through the implementation of state-of-the-art Technology, Expertise, and Safety combined with the highest level of Quality and Service, with the goal of reducing total well expenditure and Non-Productive Time (NPT) for our clients. Our team is comprised of decades of experience and knowledge in drilling services, manufacturing, and engineering with an emphasis on Managed Pressure Drilling equipment as well as the implementation of the technology which enables us to deliver Best in Class services. We are an organization that takes pride in being Customer Focused and Solutions Driven.
Flow Measurement System
The flow measurement system accurately measures the flow, density, and temperature of the drilling fluid returning from the wellbore, enabling the detection of losses and influxes in real time.
- Nominal Size 4” up to 12″
- Maximum flow: 2400 Gpm
- Mass Flow Accuracy: ± .10%
Hornet Manifold
The STASIS Hornet MPD Manifold safely controls returns from the wellbore, enabling precision pressure management throughout the well construction process.
- Modular, Available in Dual and Single Choke Models
- Manufactured and Assembled in the USA
- Compact footprint – reduced rig up time
Drilling Choke
The STASIS Drilling Choke provides reliable wellbore pressure control in Managed Pressure Drilling, Underbalanced Drilling, and Well Pressure Control.
- 3” trim size
- Maximum Working Pressure: 5,000 PSI
- Reversible tungsten carbide gate and seat
MPD Control System
The STASIS IMPACCT™ control system enables precise and automated control of the managed pressure drilling process, resulting in enhanced operational efficiency.
- HMI – allows rig floor control
- Automated control of backpressure
- Optional drilling fluid hydraulic model
Benefits of MPD
Mud Weight on Demand
Instantly change the equivalent mud weight at the target formation in the open hole based on real-time feedback. This allows users to successfully navigate the uncertainties of the most challenging drilling environments.
Well Optimization
Eliminates many of the non-productive time (NPT) events normally encountered in conventional drilling. Also decreases the flat time associated with conventional operations, resulting in lowered AFE cost to reach the same depth.
Wellbore Stability
Establishes a stable wellbore from planning through execution by ensuring an equivalent mud weight above the stability limit during all operations. Also lessens the amplitude and frequency of the downhole pressure cycles to minimize wellbore fatigue.
Well Integrity
Maintains control of all fluids/gas within the wellbore to prevent unplanned events and reach well objectives during all phases of the well construction process.
ENGINEERING services
MPD 360
Our MPD philosophy ensures every aspect of your drilling program is reviewed and evaluated during the design, execution, and close out of each MPD Project, including:
- MPD Feasibility Analysis
- MPD Section Roadmap
- Well Hydraulics Modeling
- MPD Section Recap
MPD Feasibility Analysis
We conduct an initial analysis of the project’s operational and technical objectives to determine:
- Feasibility of MPD resolving the issue
- Scope of MPD implementation required
- MPD techniques to be applied
- MPD equipment requirements
MPD Section Roadmap
We will create a detailed step-by-step section plan developed from:
- Determination of well pressure profiles required for MPD implementation
- Optimization of the mud, casing, and cementing program utilizing MPD techniques
- Holistic tripping plans based on the project’s technical and operational constraints
- Contingency procedures based on each project’s unique risks and operating environment
MPD Section Recap
We conduct a thorough review of MPD operations informed by continuous improvement methodologies. This ensures lessons learned are applied to your next MPD project.
Project Engineering/Management
The Stasis team is available to assist you throughout the entire MPD process – either as an external consultant or as a member of your in-house team. The level of support depends on project needs. Services include:
- 24/7 Remote Technical Support
- Onsite MPD Project Supervision and Engineering
- MPD Equipment Integration Plans
- Customer Training and Hazard Analysis
Rig Integration
Our team will develop an individualized MPD integration plan to ensure seamless rig integration based on:
- Customer objectives, timeline, and constraints
- Individual rig and fleet surveys
- Detailed equipment layout and design
- Implementation & training programs
- Continued technical support after project implementation
This results in:
- Reduced installation times
- Mitigation of safety risks
- Optimization of efficiencies for the entire well
Interested in our engineering services?
Click here to submit your inquiry.
